Hybride Verbunde

Hybride Laminate bieten die Möglichkeit die bereits herausragenden mechanischen Eigenschaften von Faserverbunden weiter zu steigern. Beispiele hierfür können die erhöhte Schwingfestigkeit, eine erhöhte Schädigungstoleranz beim Impact oder das maßgeschneiderte Dämpfungsverhalten sein. Um das strukturmechanische Verhalten von hybriden Laminaten und Bauteilen präzise vorherzusagen, nutzen wir nebst geeigneten komplexen Materialmodellen auch eine effiziente Modellierung auf Laminatebene. So kann ein Kompromiss zwischen Prognosegüte und Rechenzeit gefunden werden. Aktuell beschäftigen wir uns insbesondere mit dem optimierten Dämpfungsverhalten von Leichtbaustrukturen durch Elastomerschichten im Laminat.



Forschungsschwerpunkte
  • Vorhersage des Vibrationsverhalten von Laminaten mit viskoelastischen Schichten
  • Simulative Abbildung verschiedener Schädigungsarten im Laminat
  • Entwicklung analytischer Ansätze für eine schnelle Analyse unterschiedlicher Laminatkonfigurationen



Forschungsprojekte
Ansprechpartner

M.Sc. Alexander Jackstadt
Tel.: +49 721 608-45365
Email: alexander.jackstadt∂kit.edu



Bild FAST-LB
Finite Elemente Modell eines hybriden CFK/ Elastomer/Metall-Laminats

Ausgewählte Veröffentlichungen im Forschungsfeld


Continuous Simulation of a Continuous-Discontinuous Fiber Reinforced Thermoplastic (CoDiCoFRTP) Compression Molding Process
Schreyer, L.; Scheuring, B. M.; Christ, N.; Blarr, J.; Krauß, C.; Liebig, W. V.; Weidenmann, K. A.; Böhlke, T.; Hrymak, A.; Kärger, L.
2024. Proceedings of the 2023 International Conference on Composite Materials, Belfast, 30th July - 4th August 2023, Queen’s University Belfast
The influence of impact damage on the damping behavior of constrained layer damping laminates
Jackstadt, A.; Kärger, L.; Weidenmann, K. A.
2023, Juli 31. 23rd International Conference on Composite Materials (ICCM 2023), Belfast, Vereinigtes Königreich, 31. Juli–4. August 2023
HyCEML – Hybrid CFRP Elastomer Metal Laminates Containing Elastomeric Interfaces for Deliberate Dissipation
Jackstadt, A.; Sessner, V.; Liebig, W.; Kärger, L.; Weidenmann, K.
2024. Calm, Smooth and Smart. Ed.: P. Eberhard, 105–125, Springer Nature Switzerland. doi:10.1007/978-3-031-36143-2_6
Development of a test-method for characterization of the orientation dependent material properties of FFF structures
Frölich, F.; Bechtloff, L.; Scheuring, B. M.; Heuer, A.; Kärger, L.; Liebig, W. V.
2023, August 3. 23rd International Conference on Composite Materials (ICCM 2023), Belfast, Vereinigtes Königreich, 31. Juli–4. August 2023
The influence of impact damage on the damping behavior of constrained layer damping laminates
Jackstadt, A.; Kärger, L.; Weidenmann, K. A.
2023, Juli 31. 23rd International Conference on Composite Materials (ICCM 2023), Belfast, Vereinigtes Königreich, 31. Juli–4. August 2023
Modeling and parameter identification for predicting the Mullins Effect of rubbers used in constrained-layer damping applications
Jackstadt, A.; Frölich, F.; Liebig, W. V.; Weidenmann, K. A.; Kärger, L.
2021, März 16. 91st Annual Meeting of the International Association of Applied Mathematics and Mechanics (GAMM 2021), Kassel, Deutschland, 15.–19. März 2021
Challenges in characterization of polylactic acid (PLA) for thermomechanical material modeling in material extrusion
Frölich, F.; Dörr, D.; Jackstadt, A.; Kärger, L.
2022, Juli 4. 11th European Solid Mechanics Conference (2022), Galway, Irland, 4.–8. Juli 2022
Investigation into the influence of the Mullins effect on the dynamic behavior of hybrid laminates
Jackstadt, A.; Frölich, F.; Liebig, W. V.; Kärger, L.; Weidenmann, K. A.
2022, Juli 7. 11th European Solid Mechanics Conference (2022), Galway, Irland, 4.–8. Juli 2022
Hybrid material additive manufacturing: interlocking interfaces for fused filament fabrication on laser powder bed fusion substrates
Englert, L.; Heuer, A.; Engelskirchen, M. K.; Frölich, F.; Dietrich, S.; Liebig, W. V.; Kärger, L.; Schulze, V.
2022. Virtual and Physical Prototyping, 17 (3), 508–527. doi:10.1080/17452759.2022.2048228
Analytical modeling and investigation of constrained layer damping in hybrid laminates based on a unified plate formulation
Jackstadt, A.; Liebig, W. V.; Kärger, L.
2022. International journal of mechanical sciences, 216 (216), Art.Nr.: 106964. doi:10.1016/j.ijmecsci.2021.106964
Modeling the Mullins effect of rubbers used in constrained‐layer damping applications
Jackstadt, A.; Frölich, F.; Weidenmann, K.; Kärger, L.
2021. Proceedings in applied mathematics and mechanics, 21 (1), e202100098. doi:10.1002/pamm.202100098
Extension of an analytical solution of a unified formulation to the frequency response of composite plates with viscoelastic layers
Jackstadt, A.; Kärger, L.
2021. Proceedings in applied mathematics and mechanics, 20 (1), Art.-Nr.: e202000234. doi:10.1002/pamm.202000234
Numerical and experimental investigations of the damping behaviour of hybrid CFRP-elastomer-metal laminates
Liebig, W. V.; Sessner, V.; Weidenmann, K. A.; Kärger, L.
2018. Composite Structures, 202, 1109–1113. doi:10.1016/j.compstruct.2018.05.051
